Model No.: 10mm
Brand: OEM
Origin: China
Certification: ISO,ROHS
Place Of Origin: China
Use: Microduct connection
Warranty Time: 12 months
IP Rate: IP68
Temp Resistance: -20~ +50℃
Body: Polycarbonate
Seal: NBR
Washer: Polyacetal
Lock Claws: Polyacetal
Tube Assembly: No tooling required
According To Standards: CEI EN 50411-2-8,EN 50411-2-5
| Selling Units: | Piece/Pieces |
| Package Type: | Carton or Customized |
The file is encrypted. Please fill in the following information to continue accessing it
| Tube to connector | Polyethylene HDPE |
| Fluid | Air with blowing system |
| Working Pressure | 20 bar |
| MAX. Pressure | 28 bar |
| Userful life | 25 years |
| Tube assembly | No tooling required |
| Water ingress test | 0.5 bar during 168 hours |
| Working temperature | -45℃/+50℃ |
| Transport and storage temperature | -10℃/+50℃ |
| Installation temperature | -10℃/+50℃ |
| Recommended blowing temperature | -15℃/+35℃ |
| Outdoor exposure limit @Cetral Europe | 12 months |
| Protection class | IP68 |
| High pressure resistance(safety) | >50bar |
| According to Standards | CEI EN 50411-2-8,EN 50411-2-5 |
| Related documents | EN61300,EN61753-1,EN60068-2-10,EN60794-1-2:2003 |
| Related documents | ISO 3601,ISO 4397:1993(2000),ISO4399:1995 |
| Model | D | A | L | Weight(g) |
| ERPUB3 | 3 | | | |
| ERPUB4 | 4 | | | |
| ERPUB5 | 5 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
| ERPUB6 | 6 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
| ERPUB7 | 7 | 15.2±0.2 | 19.2±0.5 | 2.6±0.1 |
| ERPUB8 | 8 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
| ERPUB8.5 | 8.5 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
| ERPUB10 | 10 | 17.5±0.2 | 20.4±0.5 | 3.3±0.1 |
| ERPUB12 | 12 | 21.5±0.2 | 23.5±0.5 | 5.85±0.1 |
| ERPUB14 | 14 | 23.5±0.2 | 24.5±0.5 | 6.70±0.1 |
| ERPUB15 | 15 | 25.3±0.2 | 25.8±0.5 | 7.80±0.1 |
| ERPUB16 | 16 | 25.3±0.2 | 25.8±0.5 | 7.80±0.1 |
| ERPUB18 | 18 | 32.7±0.3 | 27.8±0.5 | 15.05±0.2 |
| ERPUB20 | 20 | 32.7±0.3 | 27.8±0.5 | 14.85±0.2 |
| ERPUB25 | 25 | | | |
| ERPUB1/8 | 1/8 | | | |
| ERPUB3/16 | 3/16 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
| ERPUB1/4 | 1/4 | 13.5±0.2 | 14.3±0.5 | 1.86±0.1 |
| ERPUB5/16 | 5/16 | 15.2±0.2 | 19.2±0.5 | 2.4±0.1 |
| ERPUB3/8 | 3/8 | 17.5±0.2 | 20.4±0.5 | 3.3±0.1 |
| ERPUB1/2 | 1/2 | 21.5±0.2 | 23.5±0.5 | 5.85±0.1 |
