Model No.: 14/10mm
Brand: OEM
Origin: China
Certification: ISO,ROHS
Place Of Origin: China
Use: Microduct connection
Warranty Time: 12 months
IP Rate: IP68
Temp Resistance: -20~ +50℃
Body: Polycarbonate
Seal: NBR
Washer: Polyacetal
Lock Claws: Polyacetal
Tube Assembly: No tooling required
According To Standards: CEI EN 50411-2-8,EN 50411-2-5
| Selling Units: | Piece/Pieces |
| Package Type: | Carton or Customized |
The file is encrypted. Please fill in the following information to continue accessing it
| Tube to connector | Polyethylene HDPE |
| Fluid | Air with blowing system |
| Working Pressure | 20 bar |
| MAX. Pressure | 28 bar |
| Userful life | 25 years |
| Tube assembly | No tooling required |
| Water ingress test | 0.5 bar during 168 hours |
| Working temperature | -45℃/+50℃ |
| Transport and storage temperature | -10℃/+50℃ |
| Installation temperature | -10℃/+50℃ |
| Recommended blowing temperature | -15℃/+35℃ |
| Outdoor exposure limit @Cetral Europe | 12 months |
| Protection class | IP68 |
| High pressure resistance(safety) | >50bar |
| According to Standards | CEI EN 50411-2-8,EN 50411-2-5 |
| Related documents | EN61300,EN61753-1,EN60068-2-10,EN60794-1-2:2003 |
| Related documents | ISO 3601,ISO 4397:1993(2000),ISO4399:1995 |
| Model | D1 | D2 | A1 | A2 | B | L | Weight(g) |
| ERPU3/2.1 | 3 | 3 | 11±0.2 | 11±0.2 | 2.1±0.12 | 30.7±0.5 | - |
| ERPU4/2.5 | 4 | 4 | 11±0.2 | 11±0.2 | 2.1±0.12 | 30.7±0.5 | - |
| ERPU5/3.5 | 5 | 5 | 13.5±0.2 | 13.5±0.2 | 3.5±0.12 | 35.8±0.5 | 3.6±0.1 |
| ERPU6/3.5 | 6 | 6 | 13.5±0.2 | 13.5±0.2 | 3.5±0.12 | 35.8±0.5 | 3.6±0.1 |
| ERPU7/3.5 | 7 | 7 | 15.2±0.2 | 15.2±0.2 | 3.5±0.12 | 41.2±0.5 | 5.2±0.1 |
| ERPU7/5.5 | 7 | 7 | 15.2±0.2 | 15.2±0.2 | 5.5±0.12 | 41.2±0.5 | 5.4±0.1 |
| ERPU8/6 | 8 | 8 | 15.2±0.2 | 15.2±0.2 | 6±0.12 | 41.2±0.5 | 4.7±0.1 |
| ERPU8.5/6 | 8.5 | 8.5 | 15.2±0.2 | 15.2±0.2 | 6±0.12 | 41.2±0.5 | 4.7±0.1 |
| ERPU10/6 | 10 | 10 | 17.5±0.2 | 17.5±0.2 | 6±0.12 | 45.2±0.5 | 6.6±0.1 |
| ERPU10/8 | 10 | 10 | 17.5±0.2 | 17.5±0.2 | 8±0.12 | 45.2±0.5 | 6.7±0.1 |
| ERPU12/10 | 12 | 12 | 21.5±0.2 | 21.5±0.2 | 10±0.12 | 52.2±0.5 | 11.8±0.1 |
| ERPU14/10 | 14 | 14 | 23.5±0.2 | 23.5±0.2 | 10±0.12 | 52.2±0.5 | 12.95±0.1 |
| ERPU14/11 | 14 | 14 | 23.5±0.2 | 23.5±0.2 | 11±0.12 | 52.2±0.5 | 12.95±0.1 |
| ERPU14/12 | 14 | 14 | 23.5±0.2 | 23.5±0.2 | 12±0.12 | 52.2±0.5 | 12.85±0.1 |
| ERPU15/12 | 15 | 15 | 25.3±0.2 | 25.3±0.2 | 12±0.12 | 52.2±0.5 | 14.6±0.2 |
| ERPU16/12 | 16 | 16 | 25.3±0.2 | 25.3±0.2 | 12±0.12 | 52.2±0.5 | 14.5±0.2 |
| ERPU16/14 | 16 | 16 | 25.3±0.2 | 25.3±0.2 | 14±0.12 | 52.2±0.5 | 14.5±0.2 |
| ERPU18/12 | 18 | 18 | 32.7±0.3 | 32.7±0.3 | 12±0.12 | 55.9±0.5 | 29.8±0.2 |
| ERPU18/14 | 18 | 18 | 32.7±0.3 | 32.7±0.3 | 14±0.12 | 55.9±0.5 | 29.8±0.2 |
| ERPU18/15 | 18 | 18 | 32.7±0.3 | 32.7±0.3 | 15±0.12 | 55.9±0.5 | 29.8±0.2 |
| ERPU20/16 | 20 | 20 | 32.7±0.3 | 32.7±0.3 | 16±0.12 | 55.9±0.5 | 27.8±0.2 |
| ERPU20/17 | 20 | 20 | 32.7±0.3 | 32.7±0.3 | 17±0.12 | 55.9±0.5 | 27.8±0.2 |
| ERPU22/16 | 20 | 20 | 40±0.3 | 40±0.3 | 16±0.12 | 71±0.5 | 47.7±0.2 |
| ERPU25/22 | 25 | 25 | 40±0.3 | 40±0.3 | 22±0.12 | 71±0.5 | 47.7±0.2 |
| ERPU1/8(2.1) | 1/8 | 1/8 | 11±0.2 | 11±0.2 | 2.1±0.12 | 30.7±0.5 | - |
| ERPU3/16(3.5) | 3/16 | 3/16 | 13.5±0.2 | 13.5±0.2 | 3.5±0.12 | 35.8±0.5 | 3.6±0.1 |
| ERPU1/4(3.5) | 1/4 | 1/4 | 13.5±0.2 | 13.5±0.2 | 3.5±0.12 | 35.8±0.5 | 3.6±0.1 |
| ERPU5/16(6) | 5/16 | 5/16 | 15.2±0.2 | 15.2±0.2 | 6±0.12 | 41.2±0.5 | 5.4±0.1 |
| ERPU3/8(8) | 3/8 | 3/8 | 17.5±0.2 | 17.5±0.2 | 8±0.12 | 45.2±0.5 | 6.7±0.1 |
| ERPU1/2(10) | 1/2 | 1/2 | 21.5±0.2 | 21.5±0.2 | 10±0.12 | 52.2±0.5 | 11.8±0.1 |
Packaging: Carton or Customized
Productivity: 10000 Piece/Pieces per Week
Transportation: Ocean,Land,Air,Express
Place of Origin: China
Supply Ability: 10000 Piece/Pieces per Week
Certificate: ISO,ROHS
HS Code: 3917400000
Port: Shenzhen,Guangzhou
Payment Type: L/C,T/T,Paypal,others,Cash
Incoterm: FOB,CFR,CIF,EXW,FAS,FCA,Express Delivery
